WEILIRAM surface mount LED canopy luminaires are low profile, lightweight and designed for long service life and easy maintenance. The fixtures are designed to make possible the easy replacement of existing canopy lighting fixtures. The robust design paired with universal mounting makes them ideal for locations, such as retail canopies, where heavy pedestrian traffic makes maintenance difficult.
The housing unit is constructed from heavy-duty aluminum. Fixtures are finished with a durable white polyester powder coating. To ensure weather-tight protection, each optical assembly is sealed with a silicone gasket. Each unit is IP65 certified to withstand wet locations. Luminaires are rated for an ambient operating temperature range of -40 C to 40 C.
High-performance, UV stabilized acrylic optics are used to achieve precise photometric distributions.
The Class II power supply has a range of 120-277V, 50/60 Hz. 0-10V dimming capability is standard. Each fixture has a built-in 10kV surge protector.
The fixture is designed for universal surface and pendant mounting. IT IS THE CUSTOMERS RESPONSIBILITY TO VERIFY THE AVAILABILITY OF ADEQUATE SPACE FOR INSTALLATION.
| MODEL | POWER | No.of LED /Module | Voltage | POWER FACTOR | CCT | CRI | LUMEN TESTED (lm) |
| ZXTB1001 | 30W | 16/1 | 100-277V | >0.9 | 3000-6500K | >70 | >5500 |
ZXTB1002 | 60W | 32/2 | 100-277V | >0.9 | 3000-6500K | >70 | >10200 |
| ZXTB1003 | 90W | 48/3 | 100-277V | >0.9 | 3000-6500K | >70 | >15300 |
| ZXTB1004 | 120W | 64/4 | 100-277V | >0.9 | 3000-6500K | >70 | >20400 |
| ZXTB1005 | 150W | 80/5 | 100-277V | >0.9 | 3000-6500K | >70 | >25500 |
| ZXTB1006 | 180W | 96/6 | 100-277V | >0.9 | 3000-6500K | >70 | >30600 |
| ZXTB1007 | 210W | 112/7 | 100-277V | >0.9 | 3000-6500K | >70 | >35700 |
